Edwards 435 Series 4-Inch Vibrating DC Bell – 12V DC
Edwards EDW435-4E1 is a 12V DC four-inch vibrating alarm bell, delivering continuous 100 dB ringing with corrosion-resistant die-cast construction.
The Edwards Signaling 435 Series EDW435-4E1 is a 12V DC continuous-ringing alarm bell with a 4-inch (102 mm) vibrating gong. Its self-compensating solenoid repeatedly strikes the gong while power is applied, delivering an audible signal rated at 100 dB at 1 meter (90 dB at 10 feet).
A die-cast housing with a corrosion-resistant, heat-flowed epoxy finish supports surface or electrical-box mounting. The EDW435-4E1 draws approximately 0.125 A at its rated supply and carries a 1.5 VA nameplate load. This UL-listed bell is suitable for general alarm, scheduling, paging, and equipment-status indication where a mechanical ringing signal is preferred.
Manufacturer | Edwards Signaling |
Category | Alarms and Signaling |
Item Number | EDW435-4E1 |
Series | 435 Series |
Protections/ Certifications | UL Listed |
Mounting Type | Surface mount |
Dimensions | 4 in (102 mm) gong × 2-15/32 in (63 mm) depth |
Weight | 2.4 lb (1.09 kg) |
Material | Die-cast housing; epoxy finish |
Wattage/ Power Rating | 1.5 VA |
Voltage Type | DC |
Nominal Voltage | 12V DC |
AMPS/Current Rating | 0.125 A |
Spec Sheet | View Manufacturer Spec Sheet |
- Manufacturer: Edwards Signaling
- Manufacturer Model: 435-4E1
- Ward’s SKU: EDW435-4E1
- Supply Voltage: 12V DC
- Current Draw: 0.125 A
- Power Rating: 1.5 VA
- Sound Output: 100 dB at 1m / 90 dB at 10 ft
- Gong Diameter: 4 in (102 mm)
- Depth: 2-15/32 in (63 mm)
- DC Coil Resistance: 40 Ω
- Net Weight: 2.4 lb (1.09 kg)
- Audible Signal: Continuous vibrating bell
- Operating Temperature: 0°C to +49°C
- Housing: Die-cast housing with corrosion-resistant epoxy finish
- Mounting: Surface or electrical box
- Certification: UL Listed
